CAMERA HD HIKVISION PTZ 2MP 23x IR 120M Voir plus grand

DS-2AE7230TI-A CAMERA HD HIKVISION PTZ 2MP 23x IR 120M

Nouveau produit

  • • 2MP CMOS Image Sensor

    • Full HD 1080P Video Output

    • 30X optical zoom, 16X digital zoom

    • Support up the coax function

    • Privacy Masking, 3D DNR, D WDR, EIS

    • 3D intelligent positioning

    • True Day&Night

Plus de détails

DS-2AE7230TI-A

  • Camera
    Image Sensor: 1/3" Progressive Scan CMOS
    Effective Pixels: 1920(H)x1080(V)
    Signal System: PAL/NTSC
    Minimum Illumination: Color: 0.02Lux@(F1.6,AGC ON)
    B/W: 0.002Lux@(F1.6,AGC ON)
    0 lux with IR
    White Balance: Auto / Manual / ATW / Indoor / Outdoor
    AGC: Auto/Manual
    S/N Ratio: ≥ 50dB
    BLC: ON/OFF
    WDR: Support
    Shutter Time: PAL: 1-1/10,000s
    NTSC: 1-1/10,000s
    Day& Night: ICR
    Digital Zoom: 16x
    Privacy Masking: 8 privacy masks programmable
    Auto Focus: Auto / Semi-automatic / Manual
    Lens
    Focal Length: 4-120mm, 30X
    Zoom Speed: Approx.3.0s(Optical Wide-Tele)
    Angle of View: 58-21.7 degree(Wide-Tele)
    Minimum Working Distance: 10-1500mm (Wide-Tele)
    Aperture Range: F1.6-F4.4
    Pan & Tilt
    Pan Range: 360°endless
    Pan Speed: Pan Manual Speed: 0.1°-160°/s,
    Pan Preset Speed: 240°/s
    Tilt Range: -15°-90° (Auto Flip )
    Tilt Speed: Tilt Manual Speed: 0.1°-120°/s,
    Tilt Preset Speed: 200°/s
    Proportional Zoom: Rotation speed can be adjusted automatically according to zoom multiples
    Number of Preset: 256
    Patrol: 8 patrols, up to 32 presets per patrol
    Pattern: 4 patterns, with the total recording time not less than 10 minutes
    Power loss recovery: Support
    Park Action: Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan
    PTZ Position Display: ON/OFF
    Infrared
    IR irradiation distance: 120m
    IR irradiation angle: Adjustable by zoom
    Input & Output
    Turbo HD Output: 1 turbo HD1080p output, BNC
    General
    RS-485 Protocols: HIKVISION, Pelco-P, Pelco-D, self-adaptive
    Menu Language: English / Chinese
    Power Supply: 24V AC
    Power Consumption: Max. 30W(IR: 9W, Heater: 6W)
    Working Temperature/Humidity: -30 °C-65°C(-22°F-149°F)
    90% or less
    Protection Level: IP66 standard (outdoor dome)
    TVS 4,000V lightning protection, surge protection and voltage transient protection
    Dimensions: Φ220×353.4mm (Φ8.66”×13.91”)
    Weight (approx.): 4.5kg(9.92 Ibs)
    Mount Option: Long-arm wall mount: DS-1602ZJ;Corner mount: DS-1602ZJ-corner; Pole Mount: DS-1602ZJ-pole; Power box mount:DS-1602ZJ-box
