CAMERA IP UNV DOME 4MP POE IR 30 M Voir plus grand

IPC324LR3-VSPF2840-D CAMERA IP UNV DOME 4MP POE IR 30 M

Nouveau produit

Optics

 Day/night functionality

 Smart IR, up to 30 m (98 ft) IR distance

 2D/3D DNR (Digital Noise Reduction)

Compression

 Ultra 265,H.265, H.264, MJPEG

 Triple streams

 ROI (Region of Interest)

Plus de détails

IPC324LR3-VSPF2840-D

  • IPC324LR3-VSPF28-D IPC324LR3-VSPF40-D
    Camera
    Sensor 1/3″, progressive scan, 4.0 megapixel, CMOS
    Lens 2.8mm@F2.0 4.0mm@F2.0
    DORI Distance Lens (mm) Detect (m) Observe (m) Recognize (m) Identify (m)
    2.8 42 16.8 8.4 4.2
    4.0 60 24 12 6
    Angle of View (H) 104.4° 78.9°
    Angle of View (V) 54.4° 39.6°
    Angle of View (O) 135.7° 97.0°
    Adjustment angle Pan 0° ~ 360° Tilt: 0° ~ 75°
    Shutter Auto/Manual, 1 ~ 1/100000s
    Minimum Illumination Colour: 0.03Lux (F2.0, AGC ON)
    0Lux with IR
    Day/Night IR-cut filter with auto switch (ICR)
    Digital noise reduction 2D/3D DNR
    S/N >52dB
    IR Range Up to 30m (98ft) IR range
    Defog Digital Defog
    WDR DWDR
    Video
    Video Compression Ultra 265, H.265, H.264, MJPEG
    H.264 code profile Baseline profile, Main Profile
    Frame Rate Main Stream: 4MP (2592*1520), Max 20fps;
    Sub Stream: 720P (1280*720), Max 20fps;
    Third Stream: D1 (720*576), Max 20fps
    HLC Supported
    BLC Supported
    OSD Up to 4 OSDs
    Privacy Mask Up to 8 areas
    ROI Up to 2 areas
    Motion Detection Up to 4 areas
    Network
    Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, QoS
    Compatible Integration ONVIF (Profile S, Profile T), API
    Interface
    Network 1 RJ45 100M Base-TX Ethernet
    General
    Power DC 12V±25%, PoE (IEEE 802.3af)
    Power consumption: Max 4W
    Dimensions (Ø x H) Φ109 x 81mm (Ø4.3” x 3.2”)
    Weight 0.35kg (0.77lb)
    Working Environment -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
    Ingress Protection IP67
    Vandal Resistant IK10
