NVR DAHUA 16/32/64 CHANNEL 1.5U 16POE UP TO 12MM Voir plus grand

NVR5432-16P-4KS2 NVR DAHUA 16/32/64 CHANNEL 1.5U 16POE UP TO 12MM

Nouveau produit

16/32/64 Channel 1.5U 16PoE 4K&H.265 Pro Network Video Recorder

H.265/H.264/MJPEG/MPEG4 codec decoding
Max 320Mbps incoming bandwidth
Up to 12Mp resolution preview&playback
2HDMI/VGA simultaneous video output
3D intelligent positioning with Dahua PTZ camera

Plus de détails


  • Description

    Main Processor Quad-core embedded processor
    Operating System Embedded LINUX
    Interface 2 HDMI (1 HDMI up to 3840×2160, Different Source ), 1 VGA
    Resolution 3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768
    Multi-screen Display 1st screen:
    16CH: 1/4/8/9/16
    32CH: 1/4/8/9/16/25/36
    64CH: 1/4/8/9/16/25/36
    2nd screen: 1/4/8/9/16
    OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
    Video Detection and Alarm
    Trigger Events Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
    Video Detection Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering
    Alarm input 16 Channel, Low Level Effective, Green Terminal Interface
    Relay Output 6 Channel, NO/NC Programmable, Green Terminal Interface
    Tracking Trigger Event N/A
    Playback and Backup
    Sync Playback 1/4/9/16
    Search Mode Time /Date, Alarm, MD and Exact Search (accurate tosecond)
    Playback Function Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
    Backup Mode USB Device/Network/Internal SATA burner/eSATA Device
    Internal HDD 4 SATA III Ports, up to 8TB capacity for each HDD
    HDD Mode Single
    eSATA 1 eSATA port
    SAS N/A
    Auxiliary Interface
    Front Cover N/A
    USB 3 ports (2 Rear USB3.0,1 Front USB2.0)
    RS232 1 Port, for PC Communication and Keyboard
    RS485 1 Port, for PTZ Control
